FLUXNET FPM-400 PON Optical Power Meter Dual Port OLT ONT 1310/1490/1550nm SC/APC NBN
| Manufacturer | |
|---|---|
| Warranty |
1 Year |
AU$ 349.00 Excl. GST
Description
The FLUXNET FPM-400 is a compact, field-ready PON Power Meter designed for installation and maintenance of FTTX networks. It simultaneously measures upstream (1310nm) and downstream (1490/1550nm) signals at any point in a live PON without disrupting service — ideal for GPON, EPON, and similar deployments.
With user-defined thresholds, pass/fail indicators, burst mode support, and USB data export, the FPM-400 streamlines fibre testing for field technicians. It’s an essential tool for any NBN contractor, fibre installer, or service provider working with live PON networks across Australia.
Key Features:
- For NBN PON Network Testing
- Triple Wavelength Testing (1310/1490/1550nm) in real-time
- Pass/Fail Analysis with adjustable thresholds
- Burst Mode Support for upstream 1310nm signals
- Data Logging & USB Upload to PC
- User-Friendly Interface with large display
- Lightweight & Portable – ideal for fieldwork
- Powered By 4 x AA Batteries (Not included)
- Auto Power-Off & Backlight Timeout
📐 Specifications
| Wavelengths | 1310nm (up), 1490nm & 1550nm (down) |
| Measurement Range | 1310nm: –40 to +10 dBm 1490nm: –45 to +10 dBm 1550nm: –45 to +23 dBm |
| Accuracy | ±0.5 dB |
| Resolution | 0.01 dB |
| Isolation | >40 dB (inter-channel) |
| Data Storage | 99 test records |
| Battery Life | Up to 24 hours Constant (4 x AA batteries) |
| Operating Temp | –10°C to +60°C |
| Dimensions | 200 × 90 × 43 mm |
| Weight | Approx. 330 g |
In the Box:
- FPM-400 PON Power Meter SC/APC (Require 4 x AA Batteries not included)
- SCA/SCA 0.5M Short Patch cord
- USB Cable
- Software CD
- User Manual
- Cleaning Sticks (1 pack)
Condition:
NEW
1 YR Warranty
NBN Compliant
User Manual:
FLUXNET FPM-400 PON Power Meter User manualV1.1
📍 Proudly supplied by FLUXNET – Your trusted partner for optical fibre and test equipment across Australia.
🌐 fluxnet.com.au | 📞 1800 FLUXNET | 📍 Epping, VIC
Additional information
| Weight | 1 kg |
|---|---|
| Dimensions | 20 × 20 × 15 cm |
| Manufacturer | |
| Condition |
New |
| Warranty |
1 Year |
